Smart 3-phase energy meter with contactor control
- Three independent measurement channels up to 120 A each
- Contactor control (any size load it is rated for)
- Reports power, voltage, current, overall energy, and power factor
- 365 days of internal memory in case Wi-Fi is not available
- Included 3x Current Transformers 120 A
- Easy control through the Shelly app, various protocols, and platforms, as well as voice assistants
Why Shelly 3em?
Smart 3-Phase Energy Meter with Contactor Control
Many appliances, homes, and buildings use more energy than they need, leading to energy waste and higher spending. Shelly 3EM is a smart 3-phase professional energy meter that will help monitor electricity usage in real-time and get notified in case an appliance or system consumes power above a pre-set threshold. Additionally, it allows for contactor control. Smart energy metering will help you identify and eliminate any redundant energy consumption.
Connect Shelly 3EM to your Wi-Fi network. No HUB required!
Shelly 3EM monitors monophase electrical systems with up to 3 points simultaneously.
Shelly 3EM has an integrated relay with a rated current of 10A per output for contactor control.
The measurements from Shelly 3EM are stored in a free cloud for 365 days.
Set custom schedules based on a daily agenda or working hours.
Set custom scenes by combining Shelly 3EM with your other Shelly devices.
Endless use applications
When an electrical appliance is damaged, it doesn't simply stop working. Usually, it increases the amount of energy used in an attempt to compensate for its operational capacity. Since there is no visible difference in its performance, it might take months before you can identify a problem, leading to inefficiency and wasted energy. Shelly 3EM power monitoring will immediately read the increase in energy consumption and will notify you, saving you additional expenses on repairs or replacement of equipment.
Shelly 3EM is developed to monitor one, two, or three phases and allows you to monitor the status and history and the current and past electrical power consumption of each separate channel for the day, week, month, or year. Shelly 3EM exports all data in CSV format in 10-minute intervals, making data analysis and cutting back costs easy. That way, you can monitor the exact energy your electric car consumes and calculate what part of your electricity bill it forms.
Monitor your home, office, or factory, and avoid additional expenses or drops in voltage that can damage your appliances and devices. Shelly 3EM can calculate 2-way consumption: produced and used energy for each of the three phases. The device can be configured to measure three separate circuits of a mono-phase electrical system and control a contactor. View the quality of your electricity network regarding active power, reactive power, voltage, and power factor.
| POWER | |
|---|---|
| Power supply AC | 110-230V ±10%, 50/60Hz |
| Power supply DC | No |
| SPECIAL FUNCTIONS | |
| Contactor Control | Yes – Shelly 3EM has an integrated relay with a rated current of 10A per output for contactor control |
| Roller shutter mode | No |
| Device temperature protection | No |
| Overload protection | No |
| Power measurement | Yes |
| FEATURES | |
| In Box | 3x 120A current transformers that are factory calibrated with the meter for accuracy |
| Channels | 3 Channels |
| Operational temperature | 0 to + 40 °C |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Local and remote control | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| UL Listed option | No |
| CONNECTIVITY | |
| Wireless/WiFi Protocol | 802.11 b/g/n |
| Radiofrequency | 2400 – 2500 MHz |
| Range | Up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| DIMENSIONS | |
| Size | 73 mm x 57 mm x 22 mm |
