Smart four-button remote with Zigbee and Bluetooth, plus built-in magnets and an included magnetic holder for flexible placement.
2
2 Years Warranty
2 Years Warranty
This warranty covers any issues with the hardware or firmware that exist at the time of purchase or that appear within the warranty period. The warranty includes all parts of the hardware, such as the body, mechanics, and display (if applicable). However, it does not cover consumable items like batteries or accessories, as their lifespan depends on how much they are used.
Smart four-button remote with Zigbee and Bluetooth, plus built-in magnets and an included magnetic holder for flexible placement.
Multi-click action trigger - execute up to 16 pre-set actions or scenes with simple click combinations. Supports multi-click - single, double, triple, and long press
Long battery life - uninterrupted performance up to 2 years
Wire-free - no need for wiring, comes with in-built magnets, a 3M patch, and one magnetic holder included in the package
Beacon mode - If enabled, the device will emit beacons every 8 seconds
Encryption - high level of security
Full compatibility with Home Assistant and any other device that is supported by BTHome protocol (out of the box)
Compact size - portable and ease of use
Variety of placement options - 3M patch included in the box
LED indication - Blue light flashing when the Device is in pairing mode. Red light flashing when a button is pressed. The number of flashes corresponds to the number of the button presses.
Device identification
Device name: Shelly BLU RC Button 4 ZB
Device model: SBBT-104CUS
Device Bluetooth ID: 0x0016
Short description
Shelly BLU RC Button 4 ZB(the Device) is a smart four-button Bluetooth and Zigbee remote control interface. It features long battery life, multi-click control, and strong encryption. The Device has in-built magnets and a magnetic holder included in the package providing users with versatile placement and usage options.
Main features
Long battery life
Supports multi-click
Compact size, portability, and ease of use
Strong encryption
Variety of placement and usage options
Use cases
Lighting control: Assign the button to control specific lighting scenes or individual smart lights. For example, a single press could turn on/off the lights, while a long-term press could dim or brighten them.
Garage door opener: Use the strong encryption of Shelly BLU RC Button 4 ZB and control your smart garage door opener as you approach or leave your garage.
Smart blinds or curtains: Open or close motorized blinds or curtain at the touch of a button.
Location-based automation: Set the device in Beacon mode so that to trigger specific actions when you come within Bluetooth range. Use the Device for presence control, for example to keep lights on while you need to spend some time in a certain area.
Scene control: Use the 4 buttons to activate any scene or specific actions you can imagine. Each button supports single, double, triple and long push - which allows the user to make 16 different actions!
Connectivity
Bluetooth
Zigbee
User interface
Inputs
Four push buttons
To enter Bluetooth pairing mode:
Press any of the buttons 4 times. The LED starts flashing in blue and the Device enters Bluetooth pairing for one minute.
To enter Zigbee pairing mode:
Press any of the buttons 5 times. The LED starts flashing in purple and the Device enters Zigbee commissioning mode for one minute.
Factory reset
Press and hold any button for 30 sec to factory reset (possible only shortly after inserting the battery).
Outputs
LED indication
Blue light flashing when the Device is in Bluetooth pairing mode.
Purple light flashing when the Device is in Zigbee pairing mode.
Green light flashing when a button is pressed shortly. The number of flashes corresponds to the number of the button presses.
Yellow light flashing on long press.
Specifications
Quantity
Value
Physical
Size (HxWxD):
Button: 65x30x13 mm / 2.56x1.18x0.51 in
Magnetic holder (for wall switch boxes): 105x44x13 mm / 4.13x1.73x0.51 in*
Magnetic holder (for flat surfaces): 83x44x9 mm / 3.27x1.73x0.35 in
Weight:
21 g / 0.74 oz
Shell material:
Plastic
Shell color:
White
Environmental
Ambient working temperature:
-20 °C to 40 °C / -5 °F to 105 °F
Humidity:
30% to 70% RH
Electrical
Power supply:
1x 3 V battery (included)
Battery type:
CR2032
Estimated battery life:
Up to 2 years
Bluetooth
Protocol:
5 (LE)
RF band:
2402 - 2480 MHz
Max. RF power:
< 8 dBm
Range:
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
Zigbee
Protocols:
802.15.4
RF bands:
2405 to 2480 MHz
Max. RF power:
< 8 dBm
Range:
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
Microcontroller unit
CPU:
EFR32MG27
Flash:
768 kB
Firmware capabilities
Schedules:
No
Webhooks (URL actions):
No
Scripting:
No
MQTT:
No
Encryption:
Yes
Other
Supported Devices
Shelly Plus / Gen3 / Gen4 series
Shelly Pro series
*Available only for products distributed in the US market
Yes, to use this device with the Shelly Smart Control app, a gateway is necessary. Compatible gateways are Shelly BLU Gateway, or alternatively any Shelly Plus, Pro, Gen3 or Gen4 device (excluding sensors) can act as a gateway.
Is it possible to use the device without a hub?
Yes, Shelly devices (except for Wave devices) operate independently without the need for a hub. They connect directly to your Wi-Fi network, and you can control them via the Shelly Smart Control app, web interface, or through integrations with platforms like Google Home, Alexa, Home Assistant and Samsung SmartThings.
Can the device work independent or it requires a gateway?
To use BLU devices with the Shelly Smart Control app, a gateway is necessary. Compatible gateways are Shelly BLU Gateway, or you can also use any Shelly Plus, Pro, Gen3 or Gen4 device to act as a Gateway (excluding sensors).
Manage multiple devices and scenes with 16 click combos to streamline your routine. Keep it in your pocket or mount it - on a metal surface, a 3M wall patch, or to an existing wall switch - for instant control of lights, blinds, garage doors, and appliances.
Bluetooth or Zigbee operated
Dual-protocol allows easy integration with a wider range of smart home ecosystems and gateways
Multi-click action trigger
Execute up to 16 pre-set actions or scenes with simple click combinations.
Long battery life
Experience uninterrupted performance with a battery life lasting up to 2 years.
Full compatibility
Easily integrates with popular smart home hubs and ecosystems for flexible, reliable control in any setup.
SOLUTIONS
Shelly BLU RC Button 4 ZB
Smart blinds or curtains
Smart blinds or curtains
Open or close motorized blinds, roller shutters, or curtains at the touch of a button. A single press can move your blinds up and down, while a long press allows you to move them to your desired level.
Garage door opener
Garage door opener
Use the strong encryption of Shelly BLU RC Button 4 ZB and control your smart garage door opener as you approach or leave your garage.
Scene control
Scene control
Use the 4 buttons to activate any scene you can imagine. For example, set up a Movie scene to dim lights and close the blinds, or a Leaving Home scene to turn off lights and lock doors.
WHY ZIGBEE?
The communication standard for low-power, highly interconnected smart home
A Zigbee-operated smart home ecosystem offers seamless, energy-efficient connectivity for your smart devices. It ensures fast communication, supports a wide range of devices, and creates a reliable mesh network.
Universal compatibility:
Zigbee is a widespread protocol used by multiple manufacturers, which ensures a high degree of compatibility between devices.
Network topology
Zigbee uses a mesh network that allows devices to forward signals to each other, extending range and increasing reliability.
Energy efficiency
Zigbee devices are exceptionally energy-efficient, consuming minimal power, making them ideal for battery-powered devices.
Enhanced security
Zigbee uses AES-128 encryption, which ensures a high level of security for home automation.
Universal compatibility:
Zigbee is a widespread protocol used by multiple manufacturers, which ensures a high degree of compatibility between devices.
Network topology
Zigbee uses a mesh network that allows devices to forward signals to each other, extending range and increasing reliability.
Energy efficiency
Zigbee devices are exceptionally energy-efficient, consuming minimal power, making them ideal for battery-powered devices.
Enhanced security
Zigbee uses AES-128 encryption, which ensures a high level of security for home automation.
